| Brand Name: | Hua Power |
| Model Number: | AT48-100Ah |
| MOQ: | 100 |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 100000 Pieces/Month |
Specification:
| Model No. | AT48-100Ah |
| Battery type | LFP |
| Rated capacity of battery pack | 100Ah |
| Rated voltage of battery pack | 51.2V |
| Maximum charging voltage | 57.6V |
| Minimum discharge voltage | 40V |
| Rated charge/discharge current | 50A |
| Maximum charge/discharge current | 75A |
| Charging temperature range | 0 to +45°C |
| Discharge temperature range | -20°C to +50°C |
| IP lever | IP21 |
| Depth of discharge | ＞80% |
| Discharge magnification | ＜1C |
| Self-discharge (25°C) | ＜3%/Month |
| Cycle life | ＞5000 times(＜0.5C) |
| Interactive mode | (APP) LCD+Button+Bluetooth |
| Dimension | 638*520*190mm (±2mm) |
| Weight | 53.0KG |
LCD display description
Interface
