| Brand Name: | Hua Power |
| Model Number: | HC1075A |
| Payment Terms: | L/C,T/T |
| Supply Ability: | Depends on the customisation requirements. |
| Attribute | Value |
|---|---|
| Protection Level | IP54 |
| Anti-corrosion Rating | C4 |
| Cooling Method | Air Cooling |
| Noise | ≤75dB |
| Altitude | 3000m (>3000m derating) |
| Display | HMI |
| Rated Power | 500kW |
| Fire Protection | FM-200 |
| Rated Voltage | 400V |
| Communication | Ethernet |
| Certification | CE, UN38.3 |
| Maximum Current | 794A |
| Rated charge discharge rate | 0.5CP |
| Wiring Method | 3P4L+PE |
| Depth Of Discharge | 90% |
| Frequency | 50Hz/60Hz |
| Cycle Life | ≥6000 Cycles (80% SOH @ Standard) |
| Power Factor | 1 (Leading)~1 (Lagging) |
| THDi | ≤3%(Rated Power) |
| Battery Type | LiFePO4 |
| Battery Cell | 3.2V/280Ah |
| Battery Pack Configuration | 1P16S |
| Battery Pack Quantity | 15 Packs/Cluster |
| Battery Cluster Quantity | 5 Clusters |
| Rated Current | 140A*5 |
| Voltage Range | 648~864V |
| Rated Capacity | 1075.20kWh |
| Weight | 15T |
| Dimensions (W/D/H) | 6058×2438×2896mm |
| Maximum Efficiency | ≥85% |
| Air Conditioning Power | 25kW (Cooling), 9kW (Heating) |
| Temperature | -20℃~50℃ (De-Rating Over 45℃) |
| Humidity | 5%~95%RH (Non-Condensation) |
